Nameplate Specifications
| Voltage: |
115 V |
Motor Type: |
Shaded Pole |
| Thermal Protection: |
Thermally |
Speed: |
1500 rpm |
| Current: |
1 A |
Number of Speeds: |
1 |
| Frequency: |
60 Hz |
Phase: |
1 |
| Ambient Temperature: |
40 °C |
UL: |
No |
| Insulation Class: |
B |
CSA: |
Yes |
Technical Specifications
| Blower Outlet Shape: |
Rectangle |
Motor Enclosure: |
Open |
| Blower Outlet Flange: |
Yes |
Bearing Type: |
Sleeve |
General Specifications
| UPC: |
815585024552 |
Weight: |
5.80 LB |
| Packaged Length: |
9.38 IN |
Packaged Width: |
8.63 IN |
| Packaged Height: |
8.06 IN |
Country of Origin: |
Mexico |
Cross References: A.O.Smith 458, Fasco 7063-2368 7063-3869 7063-4946 7063-5031 7063-5179 7063-5313 7063-5366 7063-5921 7063-6087 7063-6439 7063-6692 7063-8255 7063-8259 7063-8322 7063-8369 7063-8503 7063-8537 7063-8571 7063-8585 7063-8873 7063-9224 7063-9534 7063-9813 7073-0344 7073-0616 7073-1480 7163-9224 70631543, Rotom RB160, 7017340, 2810681001, 8213710322, Universal Electric JA2M213N JA2M213 JA2M213NS
