Description
Nameplate Specifications
| Phase: | 1 | Output HP: | 1/8 Hp |
| Voltage: | 230 V | Speed: | 1550 rpm |
| Service Factor: | 1.0 | Frame: | 42 |
| Enclosure: | Open Air Over | Thermal Protection: | Automatic |
| Ambient Temperature: | 40 °C | Frequency: | 60/50 Hz |
| Current: | 1.1 A | Duty: | Continuous |
| Insulation Class: | B | UL: | Recognized |
| CSA: | Y | CE: | N |
| Number of Speeds: | 1 |
Technical Specifications
| Electrical Type: | Permanent Split Capacitor | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Counterclockwise Lead End |
| Mounting: | Round Belly Band | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Flat | Frame Length: | 3.58 in |
| Shaft Diameter: | 0.500 in | Shaft Extension: | 2.95 in |
General Specifications
| UPC: | 818508029023 | Weight: | 7.53 LB |
| Packaged Length: | 10.13 IN | Packaged Width: | 5.50 IN |
| Packaged Height: | 6.75 IN | Country of Origin: | Mexico |
KEY FEATURES
- OEM Direct Replacement Motor
- 5" Diameter - 42 Frame
- Permanent Split Capacitor (PSC); Capacitor Required: 5 Mfd-370 Volts (Supplied with Motor)
- Thermally Protected
- Enclosed Shaft End End-Frame and Shell, Open Lead End End-Frame, Air Over
- Class B Insulation, 40°C Ambient
- 4 Point - 4.62" Bolt Circle, Ball Bearing
- 1/2" Diameter Shaft with Flat
- 31" Leads with Terminal
