Description
Connection Diagram Dimensional Diagram
- HP: 1/2
- Voltage: 575
- RPM: 1100
- AMPs: 1.2
- Phase: 1
- Rotation: Reversible
- Frame: 48
- Enclosure: Totally Enclosed Air Over
- Speeds: 1
- Protector: Automatic
-
Ambient Temp: 60°C
- Service Factor: 1.00
- Shaft Dimensions: 1/2" x 6-1/2"
- Frequency: 60Hz
- Diameter: 5-5/8"
- Length: 5"
- Bearings: Ball
- Capacitator Rating: 7.5MFD-370V
- Features: Class "B" Insulation, Reversing Plug, Thru-Bolts, 47" Leads
- Weight: 17lbs
- References: A.O. Smith 9426, A.O. Smith F48H87A01, A.O. Smith F48M48A50, GE 5KCP39PGT377, Universal Electric 9426, Universal Electric HF3K034, Universal Electric HF3K7034, York 024-27670-000
