D1103, HVAC/R Motors, OEM Replacement

Dimensional Diagram

• HP: 1/20
• Voltage: 208-230
• RPM: 1500
• AMPs: 1.15/1.35
• Phase: 1
• Rotation: CCWSE
• Frame: 3.3
• Enclosure: Open
• Speeds: 1
• Protector: Thermally Protected
• Ambient Temp: 40°C
• Service Factor: 1
• Shaft Dimensions: 5/16"X2.25"
• Frequency: 60Hz
• Diameter: 3.3"
• Length: 2.82"
• Bearings: Sleeve
• Features: CLASS B INSUL., 14" LEADS WITH MOLDED PLUG, EXTENDED STUDS SHAFT END AND LEAD END
• Weight: 3
• Cross Reference: Fasco No. 7163-3371/252-1195
