Description
- HP: 1/30
- Voltage: 115
- RPM: 1500
- AMPs: 1.3
- Phase: 1
- Rotation: CCWSE
- Frame: 3.3
- Enclosure: Open
- Speeds: 2
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1
- Shaft Dimensions: 5/16"X2.30"
- Frequency: 60Hz
- Diameter: 3.3"
- Length: 2.53"
- Bearings: Sleeve
- Features: Class B Insulation, 12" Leads, Extended Studs Shaft End and Lead End
- Weight: 3
- Replaces Universal/Century 81. The primary difference is that the leads extend out of the shell on the opposite shaft end, whereas the 81 had the leads on the shaft end.
