Description
- Type : Permanent Split Capacitor
- HP : 1.5
- Voltage : 208-230 / 460
- RPM : 1075
- Current (Amp) : 8.50-7.60 / 3.80
- Phase : 1
- Rotation : Reversible
- Frame : 56Z
- Enclosure : Totally Enclosed Air Over
- Speeds : 1
- Protector : Thermally Protected
- Ambient Temp : 60°C
- Service Factor : 1.00
- Shaft Dimensions : 0.625 in X 6.00 in
- Frequency : 60Hz
- Diameter : 6.5 in
- Frame Length : 17.38 in
- Bearings : Ball
- Capacitor Rating : 20Mfd-370/440Vac
- Features: Class B Insulation, Extended Bolts Shaft End, Belly Band Mount, Resilient Ring Mount, 5/8" Diameter Shaft With Flat And Keyed, Capacitor Required: 20 Mfd-370 Volts (Not Supplied with Motor)
- Weight: 45 lbs
- Cross References: Century C771
