Description
Type : Permanent Split Capacitor
HP : 1/2
Voltage : 115
RPM : 1075
Current (Amp) : 6.2
Phase : 1
Rotation : Reversible
Frame : 48
Enclosure : Open Air Over
Speeds : 3
Protector : Thermally Protected
Ambient Temp : 40°C
Service Factor : 1.00
Shaft Dimensions : 0.50 in X 5.00 in
Frequency : 60Hz
Diameter : 5.5 in
Frame Length : 5.6 in
Bearings : Ball
Capacitor Rating : Supplied With Motor (10Mfd-370Vac)
Weight: 15 lbs
Class B Insulation, Extended Bolts Shaft End, Resilient Ring Mount, Belly Band Mount, Reversing Plug, 25" Leads, 1/2" Diameter Shaft With Flat,
- References: G.E. Genteq 3587, Mars 10587, Century A.O.Smith DL1056, Emerson U.S. Motors 1865, Dayton 4M100, Fasco D701, Marathon X004, Packard 43587, Rheem WS1-12BAA3-01, Carrier Totaline P257-8587, York Source 1 S1-FHM3587
