390 HVAC/R Motors, Fan and Blower Motors

Dimensional Diagram

• Type: Permanent Split Capacitor
• HP: 1/4
• Voltage: 115
• RPM: 1050
• AMPs: 3.7
• Phase: 1
• Rotation: Reversible
• Frame: 42
• Enclosure: Open Air Over
• Speeds: 3
• Protector: Thermally Protected
• Ambient Temp: 40°C
• Service Factor: 1.00
• Shaft Dimensions: 1/2" X 6.00"
• Frequency: 60Hz
• Diameter: 5.0"
• Length: 3.67"
• Bearings: Sleeve
• Features: Extended Studs Shaft End, Resilient Ring Mounting, 31" Leads
• Weight: 12
• References: A.O.Smith Century BL6505 319P412 319P456 319P467 319P468 F42A51A13, Carrier HC37DA115 HC37SB117 HC39SB115 HC39VA120, Emerson K48HXSTZ3519 K55HXDFH2187, Fasco 7151-0057 7176-2303 7186-0138 D150, Franklin AW66164A, General Electric 5KCP29KK5211 2825 2827, Nidec U.S. Motors 1390, Century BL6505, Rotom R2390 R2395, Universal 154-004 200-014 200-083 200-088 200-096 200-100 200-1025 200-1039 86-010 86-012 86-015 86-019 DA3L004 DA3L012 DA3L014 DA3L019 DA3G013 DA3G017 DA3G019 DA3G055 DA3G078 DA3H013 DA3H017 DA3J001 DA3J002 DA3J013 DA3J017 DA3J021 DA3J026 DA3J031 DA3L008 DA3L009, SS390B Universal Electric DE3H7017, A.O. Smith 319P837, A.O. Smith 322P490, Dayton 3M710, Emerson 1390, Fasco D150, GE 10650, GE 2827, GE 5KCP29MK672, Dayton 3M598, A.O. Smith 318P079, A.O. Smith 319P412, A.O. Smith 319P456, A.O. Smith 319P467, A.O. Smith 319P468, A.O. Smith 319P663, A.O. Smith 319P847, A.O. Smith BL6519, Carrier/BDP HC37DA115, Coleman 4070-3111, Coleman 4070-4041, Emerson K55HXDFH2187, Fasco 5111V9A-L7844, Fasco 7151-0057, Fasco 7176-2303, Fasco H5A1TT37, Fasco U71A12-A3992, Fasco U71A12K-A3992, Fasco UH73A1EA4469, Fasco UH73A1E-A4469, Fasco UR51A4K2A2042, Franklin AW66164A, Franklin AY66164A, Franklin AY6844A, Franklin CR6805A, GE 02847, GE 2825, GE 2847, GE 2983, GE 5KCP29DK4045, GE 5KCP29FK532, GE 5KCP29HK664, GE 5KCP29HK664T, GE 5KCP29KG5855, GE 5KCP29KG5857, GE 5KSP29B693, GE 5KSP29BG7191, GE 5KSP29BG7191S, Johnstone Supply S88-302, Packard 70854, Universal Electric 154-004, Universal Electric 200-014, Universal Electric 200-083, Universal Electric 200-088, Universal Electric 200-096, Universal Electric 200-100, Universal Electric 200-1025, Universal Electric 200-1039, Universal Electric 86-010, Universal Electric 86-012, Universal Electric 86-015, Universal Electric 86-019, Universal Electric DA3L004, Universal Electric DA3L012, Universal Electric DA3L014, Universal Electric DA3L019, Universal Electric DE3G013, Universal Electric DE3G017, Universal Electric DE3G019, Universal Electric DE3G055, Universal Electric DE3G077, Universal Electric DE3G078, Universal Electric DE3H001, Universal Electric DE3H013, Universal Electric DE3H017, Universal Electric DE3J001, Universal Electric DE3J002, Universal Electric DE3J017, Universal Electric DE3J022, Universal Electric DE3J026, Universal Electric DE3J031, Universal Electric DE3J042, Universal Electric DE3L001, Universal Electric DE3L008, Universal Electric DE3L009, Universal Electric DE3L031
• NOTE: CENTURY 390 IS NO LONGER AVAILABLE. REPLACE BY U.S. MOTORS 1390
