Description
- Type : Permanent Split Capacitor
- HP : 1/2
- Voltage : 115 / 230
- RPM : 1650
- Current (Amp) : 8.00 / 4.00
- Phase : 1
- Rotation : Reversible
- Frame : 48YZ
- Enclosure : Open Air Over
- Speeds : 1
- Protector : Automatic
- Ambient Temp : 40°C
- CFM : N/A
- Service Factor : 1.00
- Shaft Dimensions : .0625 in X 3.25 in
- Frequency : 60Hz
- Diameter : 5.5 in
- Frame Length : 9.81 in
- Bearings : Ball
- Capacitor Rating : 20-370
- Features : Class B Insulation, Extended Bolts Shaft End, 16" Leads, 5/8" Diameter Shaft With Flat, Capacitor Required: 20 Mfd-370 Volts (Supplied with Motor)
