Description
Connection Diagram Dimensional Diagram
- HP: 1/2
- Voltage: 575
- RPM: 1625
- AMPs: 1.0
- Phase: 1
- Rotation: Reversible
- Frame: 48Y
- Enclosure: Totally Enclosed
- Speeds: 1
- Protector: Automatic
- Ambient Temp: 60°C
- Service Factor: 1.00
- Shaft Dimensions: 1/2" X 6.5"
- Frequency: 60Hz
- Diameter: 5.5"
- Length: 4.75"
- Bearings: Ball
- Features: Class 'B' Insulation, Thru-Bolts, 47" Leads
- Weight: 13
- References: A.O. Smith 9425, A.O. Smith F48H85A01, Universal Electric 9425, Universal Electric HF2J043, Universal Electric HF2J7043
