Description
Connection Diagram Dimensional Diagram
- HP: 1/2
- Voltage: 115/208-230
- RPM: 1140
- AMPs: 5.6/2.8
- Phase: 1
- Rotation: Reversible
- Frame: 48Y
- Enclosure: Totally Enclosed
- Speeds: 1
- Protector: Automatic
-
Ambient Temp: 60°C
- Service Factor: 1.00
- Shaft Dimensions: 1/2" x 4-1/2"
- Frequency: 60Hz
- Diameter: 5-5/8"
- Length: 7.25"
- Bearings: Ball
- Capacitator Rating: Supplied with Motor
- Features: Class "B" Insulation, Capacitator Mounted, Resilient Base
- Weight: 19lbs
- References: A.O. Smith 733, A.O. Smith F48Y59A01, Century 152665, Century C749, Fasco D817, Universal Electric HF3L069, Universal Electric HF3L7069
