Description
- Type : Permanent Split Capacitor
- HP : 1/2
- Voltage : 115 / 230
- RPM : 1625
- Current (Amp) : 5.10 / 2.90
- Phase : 1
- Rotation : Counterclockwise Lead End
- Frame : 48
- Enclosure : Open Air Over
- Speeds : 1
- Protector : Automatic
- Ambient Temp : 40°C
- CFM : 800
- Service Factor : 1.00
- Shaft Dimensions : 0.50 in X 2.63in
- Frequency : 50/60Hz
- Diameter : 5.6 in
- Frame Length : 4.50 in
- Bearings : Ball
- Capacitor Rating : 5Mfd-370Vac
- Weight: 26 lbs
- Features: Class B Insulation, Extended Bolt Shaft End, 1/2" Diameter Shaft With Flat, Capacitor Required: 5 Mfd-370 Volts (Supplied With Motor)
- Cross References: A.O. Smith F48AB73E09, Universal Electric HE2H122
- *Motor Only See No. SS800
