Description
- HP: 9W
- Voltage: 230
- RPM: 1550
- AMPs: 0.35
- Phase: 1
- Rotation: CCWSE
- Frame: Unit Bearing
- Enclosure: Totally Enclosed Air Over
- Speeds: 1
- Protector: Sensata 150°C Cut-Off
- Ambient Temp: 40°C
- Service Factor: 1.00
-
Shaft Dimensions: 0.275 in X 0.63 in (Hubless)
- Frequency: 60Hz
- Diameter: 3.3 in
- Length: 2.56 in
- Bearings: Sleeve
- Features: Class B Insulation, Shaft with 4 End-Studs, 21-23" Leads with Ring Terminals, One Foot, Front Shroud, 3 Tapped Rear Holes
- Weight: 3 lbs
- Cross References: Elco EC9W230 NUT6B09PUN01 EC-9W230 NUT6B09PUN201, M4Q045-CA01-01 M4Q045-CA25-04 NET2T12PVN001 NU9-20-4, VN10-20/317, 810021R, 810151R, 810152R, 810153R, 810154R, 81015R, 810222R, 810223R, 810224R, 810225R, 810226B, 810227B, 81022R, 810A13G, 810A14G, 810A15G, 810A16G, 810A211B, 810A21B, 810A28B, 810E009A71, 810E009A79, 810G009A11, 810G009A25, 810G009A96, 810G009B25, 810G009B26, 810M009A09, 810M009A79, 810M009B10, 810M009B22, 810M009B28, 810M009B47, 810M009B49, 810M009C08, EC9W230, NU9204, NU9204010, NUT6B09PUN201, TFM92
