Description
Connection Diagram Dimensional Diagram
- HP: 1/3
- Voltage: 115/230
- RPM: 1725
- AMPs: 3.6/1.8
- Phase: 1
- Rotation: Reversible
- Frame: 48Z
- Enclosure: Totally Enclosed
- Speeds: 1
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 3.14 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 6.00 in
- Bearings: Ball
- Features: Class B Insulation, Resilient Base, Extended Studs Shaft End
- Weight: 20
- References: A.O. Smith F48Y95A01, A.O. Smith C043, A.O. Smith F48Y34A01, Baldor CHC3416A, Dayton 4M252, Leeson 100804, Marathon W48A17T2003, Marathon X025, Universal Electric HF2J035, Universal Electric HF2J071, Universal Electric HF2J7035
