Description
- Type: Permanent Split Capacitor
- HP: 1/4
- Voltage: 115
- RPM: 1050
- AMPs: 3.2
- Phase: 1
- Rotation: CCWLE
- Frame: 48Y
- Enclosure: Open
- Speeds: 4
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 6.52 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 3.63 in
- Bearings: Sleeve
- Features: Class B Insulation, 36.5" Leads, Resilient Ring Mounting, Belly Band Mount
- Weight: 13
- References: Emerson F55HXCBR1216, 124CW148
