Description
- Type: Permanent Split Capacitor
- HP: 1/2
- Voltage: 208-230
- RPM: 1075
- AMPs: 3.0
- Phase: 1
- Rotation: Reversible
- Frame: 48Y
- Enclosure: Semi Enclosed
- Speeds: 3
- Protector: Thermally Protected
- Ambient Temp: 60°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 4.98 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 4.38 in
- Bearings: Ball
- Features: Class B Insulation, 23" Leads, Extended Studs Shaft End, Resilient Ring Mounting, 7.5Mfd-370Vac Capacitor Required Not Included with Motor
- Weight: 17LBS
- References: A.O.Smith 48Z03A01, Fasco D2701, General Electric 5KCP39KGU533
