Description
Connection Diagram Dimensional Diagram
- Type: Permanent Split Capacitor
- HP: 1/10
- Voltage: 208-230
- RPM: 1075
- AMPs: 0.7
- Phase: 1
- Rotation: Reversible
- Frame: 48Y
- Enclosure: Totally Enclosed
- Speeds: 1
- Protector: Automatic
- Ambient Temp: 60°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 6.0 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 3.13 in
- Bearings: Sleeve
- Features: Class B Insulation, 26" Leads, Extended Studs Shaft End and Opposite Shaft End, 5Mfd-370Vac Capacitor Required Not Included with Motor
- Weight: 9lbs
- References: A.O.Smith 323P620 F48Z26A01 Carrier/BDP HC31GE232, Carrier/BDP HC33GE233, Emerson 3401, Emerson 3402, Universal Electric HE3D7106, A.O. Smith 182, A.O. Smith F48Z26A01, GE 5KCP39BGS069S, GE 5KCP39BGS162S, GE 5KCP39BGS457S, Universal Electric HE3D106
