Description
Connection Diagram Dimensional Diagram
- HP: 1/6
- Voltage: 208-230
- RPM: 1040
- AMPs: 1.3
- Phase: 1
- Rotation: CWLE
- Frame: 48Y
- Enclosure: Totally Enclosed
- Speeds: 3
- Protector: Thermally Protected
- Ambient Temp: 60°C
- Service Factor: 1.00
- Shaft Dimensions: 7.0" X 1/2" X 2.14"
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 3.25"
- Bearings: Sleeve
- Features: Lug Mount, 38" Leads with Quick Connect Terminals
- Weight: 10
- References: A.O. Smith 513, A.O. Smith F48Z44A01, Fasco 7126-0043, Fasco D864, Johnstone Supply S88-687, Marathon X272, Universal Electric HE3E150, Universal Electric HE3E7150
