Description
Connection Diagram Dimensional Diagram
- HP: 1/3
- Voltage: 115
- RPM: 1100
- AMPs: 4.7
- Phase: 1
- Rotation: Reversible
- Frame: 48Y
- Enclosure: Totally Enclosed
- Speeds: 2
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 3.05 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 6.00 in
- Bearings: Ball
- Features: Class B Insulation, 5.5" Leads with Molded Plug, Yoke Mount
- Weight: 20
- References: Johnstone Supply S88-552, A.O. Smith 647, A.O. Smith F48T16B59, A.O. Smith F48Z33A01, Century C737, Fasco D901, Dayton 3M469, Universal Electric DA2J018, Universal Electric HE3K025, Universal Electric HF3H079, Universal Electric HF3K025, Universal Electric HF3K052, Universal Electric HF3K7025
