Century 730A, HVAC/R Motors, Unit Heater Motors, Permanent Split Capacitor

Connection Diagram                Dimensional Diagram

• HP: 1/6
• Voltage: 115/208-230
• RPM: 1140
• AMPs: 2.1/1.1
• Phase: 1
• Rotation: Reversible
• Frame: 48Y
• Enclosure: Totally Enclosed
• Speeds: 1
• Protector: Automatic
• Ambient Temp: 60°C
• Service Factor: 1.00
• Shaft Dimensions: 1/2" X 5.05"
• Frequency: 60Hz
• Diameter: 5.5"
• Length: 5.25"
• Bearings: Ball
• Features: Class 'B' Insulaion, Capacitor Mounted, Resilient Base
• Weight: 12
• References: Fasco D834, GE 3206, A.O. Smith 730, A.O. Smith F48Y92A01, A.O. Smith US1016, A.O. Smith US1016NB, Century 152662, Century C746, GE 5KCP35KG144, Universal Electric HE3F246, Universal Electric HF3G052, Universal Electric HF3G7052
