Description
Connection Diagram Dimensional Diagram
- HP: 1/4
- Voltage: 115
- RPM: 1135
- AMPs: 4.5
- Phase: 1
- Rotation: CCWLE
- Frame: 48Y
- Enclosure: Totally Enclosed
- Speeds: 1
- Protector: Thermally Protected
- Ambient Temp: 60°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 3.39 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 4.38 in
- Bearings: Sleeve
- Features: Class B Insulation, 36" Leads, Resilient Base
- Weight: 16
- References: Universal Electric HE3H7297, A.O. Smith 734, A.O. Smith F48Z17A01, Century 159003, Century C041, Universal Electric C041, Universal Electric HE3J209
