Description
Connection Diagram Dimensional Diagram
- HP: 1/4
- Voltage: 115
- RPM: 1075
- AMPs: 3.9
- Phase: 1
- Rotation: Reversible
- Frame: 48
- Enclosure: Open Air Over
- Speeds: 4
- Protector: Thermally Protected
- Ambient Temp: 50°C
- Service Factor: 1.00
- Shaft Dimensions: 1/2" X 5.5"
- Frequency: 60Hz
- Diameter: 5.5"
- Length: 3.75"
- Bearings: Sleeve
- Features: Class B Insulation, 25" Leads, Flex Mount
- Weight: 14 lbs
- References: Dayton 3M977, Johnstone Supply S88-367, A.O. Smith 752, A.O. Smith F48Z16A01, A.O. Smith FML1026, Dayton 4MB42 2CDT9 3M977, Emerson K55HXMFE4382, Fasco 7126-2764 D1730, General Electric 5KCP39DGR220 5KCP39DGR320 5KCP39FGN201 5KCP39GGK247 5KCP39GGN486 5KCP39GGN754 5KCP39GGP672 5KCP39GGR296S 5KCP39HGS255 5KCP39HGS636, General Electric Catalogue No. 3782 3783, Keeprite 504176, Lennox 86H6601 97H5701, Marathon Catalogue No. X034, Rotom DD-034 R42419, Universal Electric HE3F307, Universal Electric HE3G356, Universal Electric HE3G377, Universal Electric HE3G427, Universal Electric HE3G7377 HA3H036 HA3H039 HA3H042 HA3J034
