Description
Connection Diagram Dimensional Diagram
- HP: 1/2
- Voltage: 115
- RPM: 1075
- AMPs: 8.9
- Phase: 1
- Rotation: Reversible
- Frame: 48
- Enclosure: Open Air Over
- Speeds: 4
- Protector: Automatic
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 1/2" X 5.5"
- Frequency: 60Hz
- Diameter: 5.5"
- Length: 4.88"
- Bearings: Sleeve
- Features: 25" Leads, Flex Mount
- Weight: 21 lbs
- References: A.O.Smith 324P187 F48Z12A01, A.O. Smith Catalogue No. FML1056 754, Dayton 2FGR1 3M875 3M888 4MB38, Emerson K55HXCEM6402 K55HXDEM6823 K55HXNJP4701 K55HXRSP5727 K55XDWY568 K55HXHAK2067, Fasco 7126-1358, Fasco Catalogue No. D1732, General Electric 5KCP39KGT785 5KCP39LGP516 5KCP39LGR026 5KCP39MGK114 5KCP39MGR590 5KCP39NGK246 5KCP39NGP675 5KCP39NGR073 5KCP39NGR192 5KCP39PGM058 5KCP39PGP247 5KCP39PGR224 5KCP39PGV340, General Electric Catalogue No. 3143 3787, Lennox 37J2401 45H3201 86H7101, Marathon Catalogue No. X036, Rotom R42219 Johnstone Supply S88-371, Universal Electric HE3K107 HE3L128 HE3H7334 HE3L149
