Description
- HP: 1/12
- Voltage: 115/208-230
- RPM: 1550
- AMPs: 0.9
- Phase: 1
- Rotation: Reversible
- Frame: 3.3
- Enclosure: Open Air Over
- Speeds: 1
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 0.312 in X 3.25 in
- Frequency: 50/60Hz
- Diameter: 3.3 in
- Length: 3.56 in
- Bearings: Ball
- Features: Class B Insulation, 21" Leads, Extended Studs Shaft End and Opposite Shaft End, Belly Band
- Weight: 5 lbs
- References: Emerson K33NVDGV1434, Emerson Catalogue No. 9650 9651 9652 9653 9664, Fasco 7163-3371 7190-2255 7190-2652 7190-2892 7190-2893 7190-2969 7190-3004 7190-3157, Fasco Catalogue No. D1122 D1123 D1127 D1152, General Electric 5KSM59JS5036 5KSM59JSK143 5KSM59LS2262, SS9721, US-R90721, JA2P275, 196242, Keeprite 1078535 1047779, Rotom R90721, Universal Electric JE2F030 JE2F035 JE2F008 JA2R143 JA2R161 JA2R178 JA2S004 JA2S006 JA2S044 JE2F035N, 429-482/132, S33P322TB-33, PD1125 PD1127, Y4L403D01G
