Century BL6530, HVAC/R Motors, Fan and Blower, Permanent Split Capacitor

Connection Diagram                   Dimensional Diagram

• HP: 1/3
• Voltage: 115
• RPM: 1075
• AMPs: 6.3
• Phase: 3
• Rotation: Reversible
• Frame: 42Y
• Enclosure: Semi Enclosed
• Speeds: 3
• Protector: Thermally Protected
• Ambient Temp: 40°C
• Service Factor: 1.00
• Shaft Dimensions: 0.500 in X 4.7 in
• Frequency: 60Hz
• Diameter: 5.0 in
• Length: 4.59 in
• Bearings: Sleeve
• Features: Class B Insulation, 28" Leads, Extended Studs Shaft End, Resilient Ring Mounting, Belly Band, Open Shaft End End-Frame and Shaft End Shell, Lead End End-Frame Half Open and Lead End Shell Half
• Weight: 11
• References: A.O. Smith F42B45A48, A.O. Smith F42C48A78, A.O. Smith F42D79A78, A.O. Smith F42F21A01, A.O. Smith F42F42A78, A.O. Smith F42F52A50, A.O. Smith F42F54A78, GE 5KCP29MG5859, Dayton 4M407, Dayton 4MB26
