Description
Connection Diagram Dimensional Diagram
- HP: 1/2
- Voltage: 115/230
- RPM: 1700
- AMPs: 5.5/2.8
- Phase: 1
- Rotation: Reversible
- Frame: 48Z
- Enclosure: Totally Enclosed
- Speeds: 1
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 3.14 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 6.50 in
- Bearings: Ball
- Features: Farm / AG Direct Drive Fan Motor, Class B Insulation, 1/2" Diameter Shaft with Double Flat, Resilient Base, Extended Studs Shaft End
- Weight: 24
- References: A.O. Smith C044, Dayton 4M253, Marathon W48A17T2004, Marathon X026, Universal Electric HF2K032, Universal Electric HF2T005, Universal Electric HF2T7010, A.O. Smith F48Y95A01
