C196LA HVAC/R Motors, Fan and Blower

C196LA Is No Longer Available See No. D13CPA2P49

Dimensional Diagram

• HP: 1/4
• Voltage: 115/230
• RPM: 1725
• AMPs: 4.50/2.25
• Phase: 1
• Rotation: Reversible
• Frame: 48
• Enclosure: Open Drip Proof
• Speeds: 1
• Protector: Thermally Protected
• Ambient Temp: 40°C
• Service Factor: 1.00
• Shaft Dimensions: 0.500 in X 1.56 in
• Frequency: 60Hz
• Diameter: 5.5 in
• Length: 4.94 in
• Bearings: Ball
• Features: Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive, Vertical/horizontal mounting for proper placement of the fan within airflow.
• Weight: 15 lbs
• Cross References: A.O. Smith C48AA14A01, Baldor RL1203A, Century 151290, General Electric 5KC35HNA226, A4C17DR1G, U.S. Motors D13CPA2P49, Universal Electric HP2P002, 100109
