Description
Connection Diagram Dimensional Diagram
- HP: 1/4
- Voltage: 208-230
- RPM: 1075
- AMPs: 2.0
- Phase: 1
- Rotation: Reversible
- Frame: 48
- Enclosure: Open Air Over
- Speeds: 3
- Protector: Automatic
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 1/2" X 4.5"
- Frequency: 60Hz
- Diameter: 5.5"
- Length: 3.50"
- Bearings: Sleeve
- Features: Extended Studs Shaft End, Resilient Ring Mount, Belly Band
- Weight: 11
- References: Rheem/Protech 512016501, Rheem/Protech 512302431, GE 3984, Franklin CY6643B, A.O. Smith 321P479, A.O. Smith 323P032, A.O. Smith 323P203, A.O. Smith 323P274, A.O. Smith F48SF6M9, A.O. Smith F48SG6L10, A.O. Smith F48SG6L3, A.O. Smith F48SG6MA19, A.O. Smith F48SG6MA36, A.O. Smith F48SG6MA38, A.O. Smith F48SG6MA43, A.O. Smith F48SG6MA68, A.O. Smith F48SG6MB2, A.O. Smith F48SJ6MA12, A.O. Smith F48SJ6MA53, A.O. Smith F48SJ6MB1, Carrier/BDP P257-3984, Emerson 8897, Emerson K1971, Emerson K5920, Emerson K816, Fasco D725, Franklin 80375, GE 3914, GE 3928, Dayton 3M652, Dayton 3M814, Dayton 3M852, Dayton 3M910, Leece Neville RE119, Marathon X001, Packard 63984, Packard 70203, A.O. Smith 321P424, Carrier/BDP HC39ME242, GE 3936, Rheem/Protech 511959401, Rheem/Protech 512016901, Rheem/Protech 512017301, Rheem/Protech 512017701, Rheem/Protech 512018701, Rheem/Protech 512053701, A.O. Smith 321P358, A.O. Smith F48SG6MA22, A.O. Smith 321P427, A.O. Smith 321P157, GE 5KCP39KG3115, Rheem/Protech 511716901, Rheem/Protech 511717301, Rheem/Protech 511796701, Rheem/Protech 511906401, Packard 80972, A.O. Smith F48SF6MA58X1, A.O. Smith F48SF6MA59X1, GE 5KCP39EG7329, A.O. Smith 10222S3, A.O. Smith 133, A.O. Smith 321P147, A.O. Smith 321P227, A.O. Smith 321P326, A.O. Smith 321P365, A.O. Smith 321P369, A.O. Smith 321P381, A.O. Smith 321P394, A.O. Smith 321P404, A.O. Smith 321P423, A.O. Smith 321P439, A.O. Smith 321P442, A.O. Smith 321P450, A.O. Smith 321P499, A.O. Smith 321P53, A.O. Smith 321P637, A.O. Smith 323P012, A.O. Smith 323P041, A.O. Smith 323P095, A.O. Smith 323P960, A.O. Smith 324P233, A.O. Smith 324P253, A.O. Smith D1026, A.O. Smith F48C03A02, A.O. Smith F48C38A02, A.O. Smith F48H15A01, A.O. Smith F48H15A08, A.O. Smith F48J60C04, A.O. Smith F48R06C04, A.O. Smith F48SF6MA5OX1, A.O. Smith F48SG6LL10, A.O. Smith SD1026, Carrier/BDP 40ES71576B1, Carrier/BDP HC37MB705, Carrier/BDP HC37ME126, Carrier/BDP HC37ME253, Carrier/BDP HC37SE207B, Carrier/BDP HC39MA242, Carrier/BDP HC39SA651, Carrier/BDP HC39SB231B, Carrier/BDP HC39VB230, Carrier/BDP HC41SE698B, Carrier/BDP HSG2112FF2, Carrier/BDP P257-3584, Carrier/BDP P257-8584, Duotherm H-5188, Emerson F55HXCDA1244, Emerson F55HXCTH1543, Emerson F55HXCTM1551, Emerson K5420, Emerson K55HXDFJ2188, Emerson K55HXDKB2291, Emerson K55HXDPS2657, Emerson K55HXERD3005, Emerson K55HXETT3101, Emerson K55HXETT7186, Emerson K55HXGDN3831, Emerson K55HXGYF4758, Emerson K55HXHAW4316, Emerson K55HXJGA5130, Emerson K55HXLEC5744, Emerson K8897, Emerson KA55HXBZ8684, Fedders S19532, Fedders S19600067001, Fedders S19600186002, Fedders S20300026001, Franklin 8726060141, Franklin 8726360150, Franklin 8745860160, Franklin CY6625B, Franklin CY6669B, Franklin CY6674Z, Franklin CY6688Z, Franklin F-095, GE 3584, GE 5KCP39EG9443, GE 5KCP39EGA480, GE 5KCP39FG9478, GE 5KCP39FGE292, GE 5KCP39FGN652, GE 5KCP39GG7883, GE 5KCP39GGB532, GE 5KCP39GGD257, GE 5KCP39GGE430, GE 5KCP39GGE901, GE 5KCP39GGF342, GE 5KCP39HGG794, GE 5KCP39HGG849, GE 5KCP39JGB666, GE 5KCP39KG8062, GE 5KCP39KG9478, GE 5KCP39KGE529, GE 5KSP39EGD256, GE 5KSP39HG4073, GE 5KSP39HG6302, GE 5KSP39HG6587, GE G419, GE G548, GE G584, Dayton 3M415, Dayton 3M516, Dayton 3M750, Dayton 4KA33, Dayton 4M097, Dayton 4M186, Dayton 4M584, Dayton 4MA64, Johnstone Supply S88-540, Leece Neville H00151486E, Leland Faraday EM3-984, Leland Faraday MTR-80375, Marathon 48A11D136A, Marathon W48A110636, Rheem/Protech 503879, Rheem/Protech 503927, Rheem/Protech 503933, Rheem/Protech 511959301, Rheem/Protech 512302441, Rheem/Protech 512443584, RMR D620CW14, RMR L24CW98A, RMR R3984, RMR RN4302, Trane MOT 6110, Trane MOT 6111, Universal Electric 0530, Universal Electric 530, Universal Electric HA3F008, Universal Electric HA3G011, Universal Electric HA3G031, Universal Electric HA3K005, Universal Electric HA3K007, Universal Electric HE2F022, Universal Electric HE3D008, Universal Electric HE3D044, Universal Electric HE3D062, Universal Electric HE3D063, Universal Electric HE3E064, Universal Electric HE3E219, Universal Electric HE3F005, Universal Electric HE3F033, Universal Electric HE3F039, Universal Electric HE3F079, Universal Electric HE3F121, Universal Electric HE3F156, Universal Electric HE3F182, Universal Electric HE3F188, Universal Electric HE3F211, Universal Electric HE3F217, Universal Electric HE3F269, Universal Electric HE3F279, Universal Electric HE3F282, Universal Electric HE3F378, Universal Electric HE3F711, Universal Electric HE3F7378, Universal Electric HE3G024, Universal Electric HE3G033, Universal Electric HE3G049, Universal Electric HE3G061, Universal Electric HE3G075, Universal Electric HE3G076, Universal Electric HE3G159, Universal Electric HE3G160, Universal Electric HE3G203, Universal Electric HE3G259, Universal Electric HE3H009, Universal Electric HE3H106, Universal Electric HE3K002, Universal Electric HE3K051, York 024-27879-000, Carrier/BDP P257-3384, Carrier/BDP P257-8384, Emerson 1971, Franklin CY64102Z
