Description
- HP: 0.8
- Voltage: 208-230/460
- RPM: 1075
- AMPs: 4.6/2.3
- Phase: 1
- Rotation: Reversible
- Frame: 48Y
- Enclosure: Open Air Over
- Speeds: 1
- Protector: Automatic
- Ambient Temp: 70°C
- Service Factor: 1.00
- Shaft Dimensions: 0.625 in X 3.6 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 8.25 in
- Bearings: Ball
- Features: Class F Insulation, Conduit Box, 5/8" Diameter Shaft with Flat and Keyway, Belly Band, Vertical Shaft Up
- Weight: 26
