Description
- HP: 1/4
- Voltage: 115
- RPM: 1625
- AMPs: 3.0
- Phase: 1
- Rotation: Reversible
- Frame: 48Y
- Enclosure: Open Air Over
- Speeds: 3
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 6.4 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 3.75 in
- Bearings: Ball
- Features: Class A Insulation, Design Upgrade, Converting From Sleeve Bearing to Ball Bearing, 26" Leads, Extended Studs Shaft End, Resilient Ring Mounting, Belly Band, 10Mfd-370Vac Capacitor Not Supplied with Motor.
- Weight: 12 lbs
- Cross References: A.O.Smith F48EA48A61 F48SG4L1 F48SG4L7, A.O. Smith Catalogue No. 9611, Dayton 3M896 4M133 4MA80, Emerson 1690, Marathon 48A17O152 48S17D1211, Marathon Catalogue No. X013, Rotom R42416
