Description
- HP: 1/2
- Voltage: 115
- RPM: 1075
- AMPs: 7.0
- Phase: 1
- Rotation: Reversible
- Frame: 48
- Enclosure: Open Air Over
- Speeds: 4
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 0.5 in X 5.0 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 4.25 in
- Bearings: Sleeve
- Features: Extended Studs Shaft End, Resilient Ring Mounting, Mounting Holes in Shell, Belly Band, 36" Leads with Quick Connect Terminals, Capacitor Supplied with Motor.
- Weight: 16 lbs
- Cross References: A.O. Smith F48AD79A01 F48N78A01 F48S03A50, A.O. Smith Catalogue No. ORM1056, Carrier HC43AE124, Dayton 4ME32 5HC10, Emerson K555HXKPP3345 K55HXNMF4760 K55HXWLL1130, General Electric 5460, Emerson Catalogue No. K807, Fasco Catalogue No. D2835 D806 D902, General Electric 5KCP39GGAA02 5KCP39HGS599 5KCP39JGAA01 5KCP39JGN797 5KCP39KGS018 5KCP39KGS887 5KCP39KGV234 5KCP39KGV804 5KCP39LGK882 5KCP39PGT960, General Electric Catalogue No. 3463, Marathon X033 X077, Rotom R43600, Universal Electric HE3K112, Universal Electric Stock No. 685, York 024-32022-000 51-23012-41 51-24070-02, FHM3463
