Description
- HP: 3/4
- Voltage: 115
- RPM: 1075
- AMPs: 9.1
- Phase: 1
- Rotation: Reversible
- Frame: 48
- Enclosure: Open Air Over
- Speeds: 4
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 0.500 in X 5.0 in
- Frequency: 60Hz
- Diameter: 5.5 in
- Length: 4.25 in
- Bearings: Ball
- Features: Class B Insulation, 36" Leads with Quick Connect Terminals, Extended Studs Shaft End, Resilient Ring Mounting, Mounting Holes in Shell, Belly Band. Fan and Blower, Permanent Split Capacitor
- Weight: 16
