Description
- HP: 1.5
- Voltage: 200-230/460
- RPM: 1200
- AMPs: 5.1-5.0/2.5
- Phase: 3
- Rotation: Reversible
- Frame: 56Y
- Enclosure: Open Air Over
- Speeds: 1
- Protector: Automatic
- Ambient Temp: 70°C
- Service Factor: 1.00
- Shaft Dimensions: 5/8"X6.19"
- Frequency: 600H
- Diameter: 6-1/2"
- Length: 8.65"
- Bearings: Ball
- Features: Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive
- Weight: 35
- References: 182759, 165833, 182759, 193927, H765, H766, K1819, 4MB83, S88-156, MFK-12276, 713012C-01, 879-292251-00, 879-292252-00, 879-417614-00, 77604, MOT 1272, MOT 1273, MOT 1274, MOT 2464, MOT 6077, FC3156, P48SX6V3, P48SX6V3A1, P48SX6V4A1, Carrier/BDP HD54SX680, Carrier/BDP P257-E380, Carrier/BDP P257-X503, H767, F5030, 10542, 3N470, 3N648, S88-408, M2-1134, W56T1105303, 720, CFM3166A, 1819, D6610, 111148, X503, K380
