Description
- Type : Shaded Pole
- HP : 1/25
- Voltage : 115
- RPM : 1550
- Current (Amp) : 1.15
- Phase : 1
- Rotation : Clockwise Shaft End
- Frame : 3.3
- Enclosure : Open Air Over
- Speeds : 1
- Protector : Thermally Protected
- Ambient Temp : 40°C
- Service Factor : 1.00
- Shaft Dimensions : 0.313 in X 2.55 in
- Frequency : 60Hz
- Diameter : 3.3 in
- Frame Length : 3.43 in
- Bearings : Sleeve
- Features : Class B Insulation, 12" Leads, Extended Studs Shaft End and Opposite Shaft End, Belly Band, Internally Fan-Cooled Motor
- References: A.O.Smith 307
