Description
- HP: 1/15
- Voltage: 115
- RPM: 1500
- AMPs: 2.4
- Phase: 1
- Rotation: CWSE
- Frame: 4.4
- Enclosure: Open
- Speeds: 1
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1
- Shaft Dimensions: 3/8"X2.45"
- Frequency: 60Hz
- Diameter: 4.4"
- Length: 5.97" C
- Bearings: Sleeve
- Features: Class B Insulation, 27" Leads, Extended Studs Shaft End
- Weight: 5 lbs
- Cross References: Dayton 3M569, Fasco 7108-0080 7108-0119 7108-0184 7108-2183 7108-2690 7108-2747 7108-2758 7108-5023 7108-6339 7108-2265 7108-2755, Universal Electric Stock No. 44 44A 44U, AO416B2563, Universal Electric CA2E120K CA2E136N
