Description
- Type : Capacitor Start / Capacitor Run
- HP : 1/3
- Voltage : 115 / 230
- RPM : 1140
- Current (Amp) : 4.40 / 2.30
- Phase : 1
- Rotation : Reversible
- Frame : 56H
- Enclosure : Open Drip Proof
- Speeds : 1
- Protector : No Protection
- Ambient Temp : 40°C
- CFM : N/A
- Service Factor : 1.35
- Shaft Dimensions : 0.625 in X 1.97 in
- Frequency : 60Hz
- Diameter : 5.5 in
- Frame Length : 11.31 in
- Bearings : Ball
- Capacitor Rating : 35-370
- Features : Class B Insulation, Resilient Base Mount, 5/8" Diameter Keyed Shaft, Capacitor Required: 35 Mfd-370 Volts (Supplied with Motor)
