Description
- Type : Shaded Pole
- HP : 1/75
- Voltage : 115
- RPM : 1550
- Current (Amp) : 0.60
- Phase : 1
- Rotation : Counterclockwise Shaft End
- Frame : 3.3
- Enclosure : Open Air Over
- Speeds : 1
- Protector : Thermally Protected
- Ambient Temp : 40°C
- Service Factor : 1.00
- Shaft Dimensions : 0.250 in X 2.5 in
- Frequency : 60Hz
- Diameter : 3.3 in
- Frame Length : 2.61 in
- Bearings : Sleeve
- Features : Class B Insulation, 12" Leads, Extended Studs Shaft End and Lead End, Hex Mounting Hubs Shaft End and Lead End, Belly Band Mount (Belly Band Not Included), Open Shaft End and Lead End, Enclosed Shell, Air Over.
- References: A.O.Smith 370
