Description
- Type : Permanent Split Capacitor
- HP : 1/2
- Voltage : 208-230
- RPM : 1075
- Current (Amp) : 4.00
- Phase : 1
- Rotation : Reversible
- Frame : 48
- Enclosure : Open Drip Proof
- Speeds : 3
- Protector : Automatic
- Ambient Temp : 40°C
- Service Factor : 1.00
- Shaft Dimensions : 0.500 in X 5.94 in
- Frequency : 60Hz
- Diameter : 5.5 in
- Frame Length : 5.16 in
- Bearings : Sleeve
- Capacitor Rating : 7.5-44
- Features : Class B Insulation, 26" Leads, Extended Studs Shaft End, Resilient Ring Mounting, Belly Band Mounting (Belly Band Not Included), Open Shaft End and Lead End, Shell Half Vented, Air Over, Capacitor Required: 7.5 Mfd-370 Volts (Not Supplied with Motor)
- References: A.O.Smith Century EM3588 D1056 0528 487, General Electric 3588, Marathon X005
