Description
Features: Class F Insulation, Extended Bolts Shaft And Opposite Shaft End, Mounting Holes In Shell, Belly Band Mount, 48" Leads, 1/2" Diameter Shaft With Double Flat, Capacitor Required: 7.5 Or 10 Mfd-370 Volts (Not Supplied With Motor)
- Type : Permanent Split Capacitor
- HP : 1/3 - 1/5
- Voltage : 208-230
- RPM : 825
- Current (Amp) : 1.90 - 1.20
- Phase : 1
- Rotation : Reversible
- Frame : 48Y
- Enclosure : Totally Enclosed
- Speeds : 2
- Protector : Automatic
- Ambient Temp : 70°C
- Service Factor : 1.00
- Shaft Dimensions : 0.50 in X 6.00 in
- Frequency : 60Hz
- Diameter : 5.5 in
- Frame Length : 11.84 in
- Bearings : Ball
- Capacitor Rating : 7.5Mfd-370Vac Or 10Mfd-370Vac
- Cross References: A.O. Smith F48AE79A01, General Electric 5KCP39PFBE40
