Description
Horsepower (HP): 1/2 HP.
Voltage: 115V (range of 115-127V) at 60 Hz, Single Phase.
Refrigerant Type: R-290 (Propane).
Cooling Capacity: 1,692 BTU/h (ASHRAE LBP).
Application Range: Low and Medium Back Pressure (L/MBP).
Evaporating Temperature Range: -35°C to 0°C (-31°F to 32°F).
Starting Torque: Normal Starting Torque (LST).
Mechanical & Electrical Details
Displacement: 7.95 cm³.
Oil Type: POE (Polyolester) or Ester oil.
Oil Charge: 150 ml.
Motor Type: RSCR (Resistive Start - Capacitive Run).
Locked Rotor Amperage (LRA): 26.7 A (some sources specify 10.3 A for 50Hz variants).
Winding Resistance: Start winding is 13.3
and run winding is 9.25
at 25°C.
Physical Characteristics
Dimensions: 9.10 in x 5.90 in x 6.70 in.
Weight: Approximately 17.20 lbs to 18.95 lbs.
Connection Sizes:
Suction: 6.1 mm.
Discharge: 4.94 mm.
Process: 6.1 mm.
