Description
- Type : Permanent Split Capacitor
- HP : 1/2
- Voltage : 208-230
- RPM : 1625
- Current (Amp) : 2.80
- Phase : 1
- Rotation : Reversible
- Frame : 48Y
- Enclosure : Open Enclosed
- Speeds : 3
- Protector : Automatic
- Ambient Temp : 40°C
- Service Factor : 1.00
- Shaft Dimensions : 0.50 in X 6.40 in
- Frequency : 60Hz
- Diameter : 5.5 in
- Frame Length : 12.05 in
- Bearings : Ball
- Capacitor Rating : 7.5-370
- Features : Class A Insulation, Extended Studs Shaft End, Resilient Ring Mount, Belly Band Mount, 1/2" Diameter Shaft With Flat, 26" Leads, Capacitor Required: 7.5MFD-370Volts (Not Supplied With Motor)
- References : FD1054 AO Smith , K055TBZ8217012B, U.S. Motors 1695
