| Phase: |
1 |
Output HP: |
0.33 Hp |
| Output KW: |
0.25 kW |
Voltage: |
100-120/200-240 V |
| Speed: |
1725/1425 rpm |
Service Factor: |
1 |
| Frame: |
48Y |
Enclosure: |
Drip Proof |
| Thermal Protection: |
Automatic |
Efficiency: |
63.7 % |
| Ambient Temperature: |
40 °C |
Frequency: |
60 Hz |
| Current: |
5.5-5.6,2.7-2.8 A |
Power Factor: |
0 |
| Duty: |
Continuous |
Insulation Class: |
B |
| KVA Code: |
L |
Drive End Bearing Size: |
6203 |
| Opp Drive End Bearing Size: |
6203 |
UL: |
Recognized |
| CSA: |
Yes |
CE: |
N |
| Number of Speeds: |
1 |
Technical Specifications
| Electrical Type: |
Split Phase |
Starting Method: |
SM |
| Poles: |
4 |
Rotation: |
Counterclockwise/Clockwise |
| Mounting: |
Rigid Base |
Motor Orientation: |
ANY |
| Drive End Bearing: |
BALL |
Opp Drive End Bearing: |
Ball |
| Frame Material: |
Rolled Steel |
Overall Length: |
9.38 in |
| Frame Length: |
5.16 in |
Shaft Diameter: |
0.630 in |
| Shaft Extension: |
1.5 in |
General Specifications
| UPC: |
722856031723 |
Weight: |
14.00 LB |
| Packaged Length: |
12.63 IN |
Packaged Width: |
6.94 IN |
| Packaged Height: |
7.50 IN |
HTC: |
8501.40.4040 |
| Country of Origin: |
Mexico |
Cross References: A.O. Smith F48A55B06, Emerson K55NXNNZ7233 174898, General Electric 5KH32GN5604 5KH32GN5637 5KH32GN5694 5KH32GNB815 3VG37 5KH3NDA1114 H712
