Nameplate Specifications
| Phase: |
3 |
Output HP: |
5.0 Hp |
| Output KW: |
3.7 kW |
Voltage: |
460/208-230 V |
| Speed: |
3450 rpm |
Service Factor: |
1.15 |
| Frame: |
Y56HZ |
Enclosure: |
Drip Proof |
| Thermal Protection: |
Thermally Protected |
Efficiency: |
86.5 % |
| Ambient Temperature: |
40 °C |
Frequency: |
60 Hz |
| Current: |
6.6/13.4-13.2 A |
Duty: |
Continuous |
| Insulation Class: |
B |
UL: |
Recognized |
| CSA: |
Y |
CE: |
N |
| Number of Speeds: |
1 |
Technical Specifications
| Electrical Type: |
Polyphase, Induction Type, Single Or Dual Voltage |
Starting Method: |
Across The Line |
| Poles: |
2 |
Rotation: |
Reversible Counterclockwise |
| Mounting: |
Rigid Base |
Drive End Bearing: |
Ball |
| Opp Drive End Bearing: |
Ball |
Frame Material: |
Rolled Steel |
| Shaft Type: |
Keyed |
Overall Length: |
15.06 in |
| Frame Length: |
9.25 in |
Shaft Diameter: |
0.875 in |
| Shaft Extension: |
2.31 in |
General Specifications
| UPC: |
786674024466 |
Weight: |
44.00 LB |
| Packaged Length: |
19.00 IN |
Packaged Width: |
12.00 IN |
| Packaged Height: |
10.00 IN |
HTC: |
8501.52.4000 |
| Country of Origin: |
Mexico |
Cross References: Carrier HD60AZ660, Century 7-193814-02 164724, Marathon 56T34D903, Rotom T2168, MC024800V, Campbell Haufeld
