Description
Marathon O010 oil burner motor (model 048C34D2024), 1/3 HP, 115 / 208-230 V, 3600 RPM, 48NZ oil burner mount, manual reset. Replaces A.O. Smith OL2032, GE 4788, Marathon 48C34D2017 and Emerson S55GYLDM6017.
Specifications
| HP | 1/3 |
| Voltage | 115 / 208-230 V |
| RPM | 3600 |
| Amps | 5.6 / 2.7-2.8 A |
| Phase | 1 |
| Speeds | 1 |
| Rotation | Counterclockwise (selective) |
| Frame | 48NZ |
| Diameter | 5-5/8" |
| Frame length | 6.75" |
| Enclosure | Open drip-proof |
| Protector | Manual reset |
| Ambient temperature | 40°C |
| Shaft | 1/2" x 1.94" with flat |
| Frequency | 60 Hz |
| Bearings | Ball |
| Insulation | Class B |
| Mounting | Oil burner flange |
| Weight | 14 lb |
Replaces these part numbers
- Marathon: 048C34D2024, 48C34D2017
- A.O. Smith: OL2032
- General Electric: 4788
- Emerson: S55GYLDM6017, 2319, 3268
Warranty and shipping
- 1-year warranty against manufacturer defects
- 30-day returns
- Orders placed before 2:00 PM ET on a business day start processing the same day
