Description
- Type: Permanent Split Capacitor
- HP: 1/8
- Voltage: 115
- RPM: 1075
- AMPs: 2.3
- Phase: 1
- Rotation: Clockwise Shaft End
-
Frame: 42 (5'' Diameter)
- Enclosure: Totally Enclosed Air Over
- Speeds: 1
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1
- Shaft Dimensions: 0.50 in X 2.20 in
- Frequency: 60Hz
- Diameter: 5"
- Length: 4"
- Bearings: Sleeve
- Features: Class B Insulation, 3 Extended Bolts Shaft End, Resilient Base Mount, 60" Leads, 1/2" Diameter Shaft with Flat, Capacitor Required: 5 Mfd-370 Volts (Supplied with Motor)
- Weight: 14 lbs
- Cross References: A.O. Smith 380 F42E62A13 U6520 U6521, Rotom R2380, Universal Electric DE3G069N DE3P001N
