Description
- Type: Shaded Pole
- HP: 1/15
- Voltage: 115
- RPM: 1600
- AMPs: 2.9
- Phase: 1
- Rotation: Counterclockwise Shaft End
- Frame: 3.3
- Enclosure: Open
- Speeds: 2
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1.00
- Shaft Dimensions: 5/16'' X 2-1/2"
- Frequency: 60Hz
- Diameter: 3.3"
- Length: 4.46"
- Bearings: Sleeve
- Features: Class B Insulation, 3 Welded Lugs, 5/16" to 3/8" Bushing, 19" Leads, 5/16" Diameter Shaft with Flat
- Weight: 4 lbs
- References: Dayton 4M301, Electrohome 2868-513-120, Fasco 7063-6169 7063-6616 7063-8671 7063-8952 7163-0616 7163-3108 7163-5176 7163-8831, Fasco Catalogue D1161 D0563, Franklin 8254110480, MacMillan J483-4T-303/7, OmniDrive 8224115210, Universal Electric JA2R225 JA2R225N, Universal Stock No. 563
