Description
- Type : Three Phase
- HP : 1
- Voltage : 575
- RPM : 1725
- Current (Amp) : 1.30
- Phase : 3
- Rotation : Reversible
- Frame : 56H
- Enclosure : Totally Enclosed Fan Cooled
- Speeds : 1
- Protector : No Protection
- Ambient Temp : 40°C
- Service Factor : 1.15
- Shaft Dimensions : 0.625 in X 1.88 in
- Frequency : 60Hz
- Diameter : 6.5 in
- Frame Length : 12.90 in
- Bearings : Ball
- Features : Class F Insulation, Rigid Base, 5/8" Diameter Keyed Shaft, Rolled Steel Frame, Shaft Slinger On Pulley End
