Description
- Type : Shaded Pole
- HP : 9 Watt
- Voltage : 230
- RPM : 1550
- Current (Amp) : 0.27
- Phase : 1
- Rotation : Clockwise Shaft End
- Frame : Unit Bearing
- Enclosure : Totally Enclosed Air Over
- Speeds : 1
- Protector : Impedence
- Ambient Temp : 40°C
- Service Factor : 1.00
- Shaft Dimensions : Threaded 1/4x20 in X 0.415 in
- Frequency : 60Hz
- Diameter : 3.3 in
- Frame Length : 3.12 in
- Bearings : Unit
- Features : Class B Insulation, 28 in Leads with 0.5 in Strip, Extended Studs Opposite Shaft End, Thermally Protected, One-Shot Fuse, Includes Vibration Dampening Hub Washer, Speed Nut and 4 Mounting Screws.
- References: Fasco D564
