Description
- Type : Permanent Split Capacitor
- HP : N/A
- Voltage : 208-230
- RPM : 3350 / 2800
- Current (Amp) : 0.42 / 0.50
- Phase : 1
- Rotation : N/A
- Frame : 3.3
- Enclosure : Open
- Speeds : 2
- Protector : Thermally Protected
- Ambient Temp : 40°C
- CFM : N/A
- Service Factor : N/A
- Shaft Dimensions : N/A
- Frequency : 60/50Hz
- Diameter : 3.3 in
- Frame Length : N/A
- Bearings : Ball
- Features : Class B Insulation, 8.5" Leads with Pin Housing Terminal, Blower Outlet Shape:Rectangle, Blower Outlet Flange:No
- References: 7062-5033, X38040369-010, Trane 7062-5033/X38040369010
