Nameplate Specifications
| Phase: |
1 |
Output HP: |
1/6 Hp |
| Output KW: |
0.13 kW |
Voltage: |
208-230 V |
| Speed: |
1550 rpm |
Service Factor: |
1 |
| Frame: |
42 |
Enclosure: |
Open Air Over |
| Thermal Protection: |
Automatic |
Ambient Temperature: |
40 °C |
| Frequency: |
60 Hz |
Current: |
1.32 A |
| Duty: |
Continuous Air Over |
Insulation Class: |
B |
| UL: |
Recognized |
CSA: |
Y |
| CE: |
N |
Number of Speeds: |
1 |
Technical Specifications
| Electrical Type: |
Permanent Split Capacitor |
Starting Method: |
Across The Line |
| Poles: |
4 |
Rotation: |
Counterclockwise Shaft End |
| Mounting: |
Resilient Base |
Drive End Bearing: |
Ball |
| Opp Drive End Bearing: |
Ball |
Frame Material: |
Rolled Steel |
| Shaft Type: |
Flat |
Frame Length: |
4.00 in |
| Shaft Diameter: |
0.500 in |
Shaft Extension: |
3.3 in |
General Specifications
| UPC: |
818508028804 |
Weight: |
10.00 LB |
| Packaged Length: |
10.00 IN |
Packaged Width: |
5.13 IN |
| Packaged Height: |
6.50 IN |
Country of Origin: |
Mexico |
Cross References: A.O.Smith OCP0251, Century 9640 593, Copeland 050-0242-00, Dayton 4MA13, Emerson F48HXNY741 F48ZZZB1727, Emerson Stock No. 722 F722, Fasco 71850412, U.S. Motors 722P, Universal Electric DA2G088 DA2H004 DA2G088N
